1.0mm 2C+E Flat TPS | 100m
STOCK QUANTITY MAY VARY, SUBJECT TO AVAILABILITY. PLEASE CONTACT US FOR ACCURATE STOCK QUANTITY & TRADE PRICING.
Got questions?
Feel free to get in touch
Couldn't load pickup availability
1.0mm TPS 2C+E Flat Cable 100m | Dominion Cables
Dominion Cables 1.0mm² 2C+E flat TPS cable is designed for general fixed wiring in residential, commercial and industrial electrical installations. Supplied on a 100m reel, this twin-and-earth cable features copper conductors, PVC V90 insulation and a white PVC outer sheath. Rated at 450/750V and manufactured to AS/NZS 5000.2, it provides a compact cable option for appropriately designed circuits. Final cable selection should always consider circuit load, protective devices, installation method, cable length, voltage drop, environmental conditions and applicable New Zealand electrical requirements.
1.0mm TPS Cable Specifications
| Specification | Details |
|---|---|
| Brand | Dominion Cables |
| Product | Flat TPS Twin & Earth |
| SKU | DC309 |
| Configuration | 2C+E / 3 conductors |
| Conductor size | 1.0mm² |
| Conductor construction | 1/1.13 solid copper |
| Conductor material | Copper |
| Insulation | PVC V90 |
| Core colours | Red, Black, Green/Yellow |
| Sheath | White PVC 3V-90 |
| Voltage rating | 450/750V |
| Reel length | 100m |
| Nominal overall dimensions | 4.5 × 9.5mm |
| Approximate mass | 85kg/km |
| Minimum installed bending radius | 55mm |
| Maximum operating temperature | 90°C |
| Standard | AS/NZS 5000.2 |
Typical Applications
1.0mm² TPS cable can be used for suitable general fixed-wiring applications where the circuit design and installation requirements allow this conductor size.
Dominion Cables specifies its flat 2C+E TPS range for general wiring installed unenclosed, in conduit, buried direct or in underground ducts for domestic, commercial and industrial installations where the cable is not subject to mechanical damage.
Cable size should be selected for the individual circuit rather than by application alone. Design current, protective device rating, installation method, grouping, thermal conditions, cable length and voltage drop can all affect the required conductor size.
Compliance & Documentation
Dominion Cables 1.0mm² flat TPS cable is manufactured to AS/NZS 5000.2 and rated at 450/750V. The manufacturer specifies PVC V90 insulation, a white PVC 3V-90 sheath and a maximum operating temperature of 90°C.
Refer to current Dominion Cables technical documentation, applicable New Zealand electrical requirements and project specifications when selecting or installing this cable.
Delivery & Trade Orders
CoreGrid360 supplies electrical products throughout New Zealand. The 1.0mm² 2C+E flat TPS cable is listed as SKU DC309 and supplied on a 100m reel.
Freight added at checkout for most other products. For multiple reels, project quantities or ongoing supply requirements, contact CoreGrid360 to confirm availability and discuss project pricing.
